GLASS AND GLAZING SHOP DRAWINGS

Services

Glass and glazing subcontractors turn to us for creation of detailed and quality submittal drawings for commercial interior and exterior aluminum, glass, and glazed structures, including:

• Storefronts
• Curtain Walls
• Entrances
• Windows
• All Glass Hand Rails, Walls and Frames
• Slope Glazing
• Custom Designs and Systems
• Composite Panels

Our professional shop drawings include:

• Cover sheet with product information
• Floor plans/building elevations if needed by customer (scaled as required)
• Frame elevations with 1/2" = 1'-0" standard scale or other scales as required per job
• Half scale details
• Shops are sent in PDF format
